56 acoustic glass units in our portfolio

13 new acoustic glazed units with the STC values ranging from 41 to 48 dB have been added to the Press Glass offer. Sound parameters of the glass were confirmed by mandatory certificates recognised on the European and North American markets.



No. Structure [mm] STC [dB] OITC [dB]
1 8,8 (Lami. 44.2) Acoustic/12Ar/6/12Ar/4 41 33
2 6,4 (Lami. 33.1) Acoustic/12Ar/4/12Ar/6,4 (Lami. 33.1) Acoustic 43 34
3 8,8 (Lami. 44.2) Acoustic/16Ar/8,8 (Lami. 44.2) Acoustic 45 34
4 6,4 (Lami. 33.1)/12Ar/4/12Ar/26,6 Pyrobel 25 46 36
5 8,4 (Lami. 44.1) Acoustic/12Ar/4/12Ar/8,4 (Lami. 44.1) Acoustic 47 38
6 8,4 (Lami. 44.1) Acoustic/12Ar/6/12Ar/8,4 (Lami. 44.1) Acoustic 47 38
7 8,8 (Lami. 44.2) Acoustic/12Ar/6/12Ar/8,4 (Lami. 44.1) Acoustic 47 38
8 8,8 (Lami. 44.2) Acoustic/12Ar/6/12Ar/8,8 (Lami. 44.2) Acoustic 47 38
9 9,5 (Lami. 44.4)/12Ar/6/12Ar/8,8 (Lami. 44.2) Acoustic 47 38
10 9,5 (Lami. 44.4)/12Ar/8/12Ar/8,8 (Lami. 44.2) Acoustic 47 38
11 8,8 (Lami. 44.2) Acoustic/12Ar/8/12Ar/8,4 (Lami. 44.1) Acoustic 48 38
12 8,8 (Lami. 44.2) Acoustic/12Ar/8/12Ar/8,8 (Lami, 44.2) Acoustic 48 38
13 10,8 (Lami. 55.2) Acoustic/12Ar/6/12Ar/8,8 (Lami. 44.2) Acoustic 48 39

Ar – noble gas – Argon
Lami. – laminated safety glass
Pyrobel 25 – fire resistant, indoor glass

We can now offer to our Customers as many as 56 different acoustic glass units within the range of 33-52 dB.

“The range of acoustic glazed units from Press Glass has been gradually extended by adding new items. We know how difficult choosing the right acoustic glass unit can be. That is why we encourage our Customers to use our dedicated tool – Soundproof Glass Configurator, which is available on our website: www.pressglass.us and in PRESS GLASS MOBILE application (for iOS and Android).

The tool contains a full list of acoustic glass units from our portfolio. The configurator enables quick checking and comparison of sound parameters of acoustic glass units. We hope that this tool will certainly facilitate choosing the preferred acoustic glass units”, says Gerard Plaze from Press Glass Promotion Department.



Soundproof glass configurator
